Cut every 3 LEDs without damaging the rest. Pair it with an SPI/SM16703 controller to get programmable white motion effects that look more refined than standard RGB strips. Reliable, low-voltage, and made for commercial decoration.
External SM16703 IC: stable single-signal control, 20 pixels/m, 1 IC drives 3 pcs 5050W LEDs.
White Running Effects: supports running horse, flowing water, chase, fade, breathe—ideal for upscale decor.
High Brightness 5050W: uniform white light, better lumen output than 2835 entry-level strips.
DC12V Safe & Cuttable: cut every 3 LEDs / 50mm, easy DIY and engineering installation.
Flexible & Wide Use: 10mm FPC, 3M adhesive, IP20/IP65/IP67 optional, great for signage, hotels, KTV, architecture outline.
|
Item |
Specification |
|---|---|
|
Model |
SM16703-5050W-60D-12V-10mm |
|
LED Type |
SMD 5050 White (5050W) |
|
IC Type |
SM16703, external IC |
|
Input Voltage |
DC 12V |
|
LED Density |
60 LEDs/m |
|
Pixel Density |
20 pixels/m (1 IC / 3 LEDs) |
|
Cutting Unit |
3 LEDs ≈ 50 mm |
|
PCB Width |
10 mm FPC |
|
Power |
12–14.4 W/m |
|
Current |
≈ 1.0–1.2 A/m |
|
Effect |
Running horse, flowing water, chase, fade, breathe |
|
Signal |
SPI / SM16703 protocol |
|
Connector |
3-pin: VCC / GND / DIN (DOUT cascade) |
|
Beam Angle |
120° |
|
CRI |
Ra ≥ 80 |
|
PCB Color |
White / Black |
|
IP Rating |
IP20 bare board (IP65/IP67/IP68 optional) |
|
Length |
5 m/reel |
|
Life Span |
30,000–50,000 h |
|
Application |
Hotel, KTV, signage, staircase, architectural outline, home decor |
