True RGBW Color Mixing: Features 5050 4-in-1 chips (Red, Green, Blue, White) for pure, high-CRI white light alongside millions of vibrant colors, eliminating the need for separate white strips.
24V Stable Operation: Powered by 24V DC, ensuring lower voltage drop, higher energy efficiency, and longer run lengths compared to 5V alternatives, perfect for commercial installations.
Precision Pixel Control: Driven by UCS2904 IC with 10 segments/m (1 IC/6 LEDs), allowing for smooth gradients, chasing effects, and detailed animations via SPI/TTL controllers.
Flexible & Cuttable: Comes in 5m rolls with cut marks every 100mm (6 LEDs), enabling custom lengths without damaging the circuit, backed by strong 3M adhesive.
Versatile Applications: Rated for IP20/IP65/IP67, suitable for indoor cove lighting, outdoor signage, media facades, and stage setups, with a lifespan of up to 50,000 hours.
|
Parameter |
Specification |
|---|---|
|
Product Model |
UCS2904-5050RGBW-60D-24V |
|
LED Type |
SMD 5050 RGBW (4-in-1) |
|
Input Voltage |
DC 24V |
|
Power Consumption |
18W/m (Max) |
|
LED Density |
60 LEDs/m |
|
IC Density |
10 ICs/m (UCS2904) |
|
Pixel Density |
10 Pixels/m (1 IC controls 6 LEDs) |
|
Cutting Unit |
Every 6 LEDs (100mm) |
|
Grayscale |
256 levels x 4 channels (32-bit color) |
|
Data Rate |
800 kbps |
|
Beam Angle |
120° |
|
PCB Width |
10mm / 12mm (Optional) |
|
PCB Color |
White / Black |
|
Length/Reel |
5 meters (Customizable) |
|
Operating Temp. |
-20°C to +60°C |
|
IP Rating |
IP20 / IP65 / IP67 / IP68 Available |
|
Lifespan |
30,000 - 50,000 hours |
|
Certification |
CE, RoHS |
|
Warranty |
2-3 Years (Manufacturer dependent) |
