Each LED is individually addressable, allowing you to create stunning dynamic effects, chasing patterns, and text displays via a compatible SPI controller (Arduino, ESP32, etc.). Despite its high density, the strip maintains excellent flexibility for bending around curves. Please note: Due to the high pixel count and 5V operation, this strip draws significant current; we recommend powering from both ends or injecting power every 0.5m to 1m to ensure consistent brightness. Unleash your creativity with this professional-grade lighting solution.
Ultra-Narrow & Discreet: Features a slim 7mm wide black PCB that hides perfectly in gaps and dark surfaces, providing a premium, low-profile look.
High-Density Pixels: Boasts 144 LEDs per meter (6.94mm pitch) using tiny 2427 chips, ensuring smooth color gradients and clear text/pattern display without "dotting."
Individually Addressable: Each LED operates independently (Single Point Control), allowing for complex chasing, rainbow, and video-sync effects via SK6812 protocol.
Vibrant Color Mixing: Delivers full-color RGB output with 256-level brightness per channel, producing millions of colors and pure white light (requires 5V).
Flexible & Cuttable: Comes as a bare board for maximum flexibility. It can be cut every single LED (6.94mm) to fit exact project lengths.
|
Parameter |
Specification |
|---|---|
|
Product Type |
Addressable RGB LED Strip |
|
Model |
SK6812-2427-144-B |
|
LED Chip |
SK6812 (Built-in IC) / 2427 SMD |
|
LED Density |
144 LEDs/Meter (144 Pixels/Meter) |
|
PCB Width |
7.0 mm (0.27 inches) |
|
PCB Color |
Black |
|
IP Rating |
IP20 (Non-waterproof / Bare Board) |
|
Operating Voltage |
DC 5V |
|
Power Consumption |
43.2W/ Meter (Max. Full White) |
|
Pixel Pitch |
6.94 mm |
|
Cutting Unit |
1 LED (6.94 mm) |
|
Control Protocol |
Single-wire SK6812 (Compatible with WS2812B) |
|
Color Resolution |
256 levels per channel (R/G/B) |
|
Recommended Use |
Architectural lighting, DIY projects, display cases, signage, ambient lighting |
