This DC5V SK6812 5050 RGBW strip gives 60 addressable pixels per meter, each 5050 package integrating red, green, blue and a dedicated white die for pure warm/natural/cool white plus vivid dream-color effects. Single-wire SK6812/WS2812B protocol means it works with Arduino, ESP32/WLED, FastLED, K-1000C, T-1000S and Madrix. Cut every 16.6mm (1 LED), 10mm PCB, 3-pin 5V/DATA/GND. 5V draws high current—plan power injection every 1–2m on long runs. Great for gaming setups, retail showcases, signage backlight, KTV, pixel murals and maker projects where RGB alone looks cheap but RGBW looks premium.
True RGBW 4-in-1: Dedicated white channel (3000K/4000K/6000K) avoids muddy RGB-mixed white; 32-bit color (8-bit × R/G/B/W).
60 Pixels/m Single Control: 1 SK6812 IC = 1 LED, 256 gray levels/channel, chase/gradient/text/video effects.
WS2812B-Compatible: Same 800kbps single-wire NZR timing; Arduino/FastLED/NeoPixel/WLED/Madrix ready (set color order to RGBW).
Maker-Friendly Footprint: 10mm FPC, cut every 16.6mm, black/white PCB, IP20/IP65/IP67 options, 3M adhesive.
5V Ecosystem Standard: Perfect for USB/ESP32/Arduino builds; just inject 5V power on long runs to avoid tail-end dimming.
|
Item |
Specification |
|---|---|
|
LED Type |
SMD 5050 RGBW (4-in-1) |
|
IC |
SK6812 (built-in, WS2812B-compatible) |
|
Density |
60 LEDs/m = 60 pixels/m |
|
Voltage |
DC 5V (do NOT exceed 5.5–6V) |
|
Power |
~13 W/m typical, 14.4–19.2 W/m max (full white) |
|
Current |
~2.6–3.6 A/m full white |
|
Cut Unit |
Every 1 LED / 16.67 mm |
|
PCB Width |
10 mm (12 mm waterproof optional) |
|
White Temp |
WW 3000K / NW 4000K / CW 6000K |
|
Color Depth |
32-bit (256/chan), PWM ~1.2 kHz |
|
Signal |
Single-wire NZR, 800 kbps |
|
Wiring |
5V / DIN / GND |
|
Beam Angle |
120° |
|
IP Rating |
IP20 / IP65 / IP67 optional |
|
Controller |
Arduino, ESP32 WLED, K-1000C, T-1000S, Madrix, SP108E |
|
Lifespan |
30,000–50,000 hrs |
|
Note |
Individually addressable; no breakpoint resume; 5V needs frequent power injection |
