Cut every 100mm, cascade with VCC/GND/DI/BI, and drive it from SD/DMX/Artnet/SPI controllers. Full-color chase, flow, breathe, and custom shows come out smooth and stable. IP20/IP65/IP67/IP68 options make it indoor-outdoor ready.
Breakpoint Continue: backup data line—one bad pixel won’t kill the whole strip.
24V Engineering Strip: 6 LEDs/pixel, lower current, longer runs with less brightness loss.
5050 RGB Bright: 60 LEDs/m, vivid full color for architecture and commercial decor.
LB1934 External IC: SPI-class, works with SD/DMX/Artnet pixel controllers; dual-signal reliability.
10mm & Field-Ready: 2oz FPC, cut every 100mm, IP20–IP68 optional, clips/3M install.
Product Specification: LB1934 5050 RGB 24V Breakpoint-Continue LED Strip
|
Item |
Specification |
|---|---|
|
Model |
LB1934-5050RGB-60D-24V-10mm |
|
LED Type |
SMD 5050 RGB |
|
IC Type |
LB1934 / LB1934A, external IC |
|
Signal |
Dual data: DI + BI (breakpoint continue / backup signal) |
|
Input Voltage |
DC 24V |
|
LED Density |
60 LEDs/m |
|
Pixel Density |
10 pixels/m (6 LEDs / pixel) |
|
Cutting Unit |
6 LEDs ≈ 100 mm |
|
PCB Width |
10 mm FPC, 2 oz copper |
|
Power |
≈ 14.4 W/m |
|
Current |
≈ 0.6 A/m @ 24V |
|
Gray Scale |
8-bit × 3CH (256/CH) |
|
Data Rate |
800 kbps |
|
Connector |
4-pin: VCC / GND / DI / BI (DO/BO cascade) |
|
Controller |
LB1934 / WS2811-class SPI, SD/DMX/Artnet pixel controller |
|
Beam Angle |
120° |
|
PCB Color |
White / Black |
|
IP Rating |
IP20 / IP65 / IP67 / IP68 |
|
Length |
5 m/reel |
|
Life Span |
30,000–50,000 h |
|
Application |
Building facade, bridge, signage, hotel exterior, landscape, KTV, mall decor |
