The 10mm FPC is flexible and easy to mount, cut every 3 LEDs, and cascade through DIN→DOUT with UCS1903B/SPI controllers. Low density means lower power, simpler programming, and stable long runs for commercial projects.
Big Pixel 10/m: 3 LEDs per pixel, bold chase/flow/rainbow
5050 RGB Bright: stronger light than 2835 low-density strips, vivid color blocks.
DC12V Easy Power: standard 12V supply, lower current than high-density tapes.
10mm Flexible FPC: fits sign edges, profiles, stairs, fences, stage frames.
Cut & Cascade: cut every 3 LEDs (100mm), DIN→DOUT, UCS1903B/SPI controller ready.
|
Item |
Specification |
|---|---|
|
Model |
UCS1903B-5050RGB-30D-12V-10mm |
|
LED Type |
SMD 5050 RGB |
|
IC Type |
UCS1903B (SPI, external IC) |
|
Input Voltage |
DC 12V |
|
LED Density |
30 LEDs/m |
|
Pixel Density |
10 pixels/m (3 LEDs / pixel) |
|
Cutting Unit |
3 LEDs = 100 mm |
|
PCB Width |
10 mm FPC |
|
Power |
≈ 7.2 W/m (typ. 6–8 W/m) |
|
Current |
≈ 0.6 A/m |
|
Gray Scale |
8-bit × 3CH (256/CH) |
|
Effect |
Chase, flow, rainbow, breathe, custom SPI animation |
|
Signal Interface |
3-pin: VCC / GND / DIN (DOUT cascade) |
|
Controller |
UCS1903B / SPI addressable controller |
|
Beam Angle |
120° |
|
PCB Color |
White / Black |
|
IP Rating |
IP20 bare board (IP65/IP67/IP68 optional) |
|
Length |
5 m/reel |
|
Life Span |
30,000 h+ |
|
Application |
Sign outline, building edge, stage trim, fence, holiday decor |
