The robust ABS base ensures excellent heat dissipation and easy mounting for various indoor projects. Perfect for building custom clocks, ambient mood lighting, or interactive art installations, this ring is compatible with popular platforms like Arduino, Raspberry Pi, and ESP32. Experience seamless cascading and professional-grade lighting control for your next innovative project.
Individually Addressable: Each 5050 LED can be controlled separately to display millions of colors and complex chasing effects via a single data line.
Built-in WS2812B IC: Integrated driver chip simplifies wiring and ensures stable signal transmission without external components.
Safe DC 5V Operation: Low voltage input provides energy efficiency and safety, ideal for long-term indoor use.
Durable ABS Material: Features a high-quality ABS base that offers superior heat resistance and mechanical protection for the LEDs.
Wide Compatibility: Fully compatible with Arduino, FastLED library, and Raspberry Pi, making it a versatile choice for any electronics hobbyist.
|
Parameter |
Specification |
|---|---|
|
Product Type |
LED Pixel Ring / Module |
|
LED Type |
SMD 5050 RGB |
|
IC Model |
WS2812B (Built-in) |
|
Operating Voltage |
DC 5V |
|
Power Consumption |
0.3W per LED (Max) |
|
Current Draw |
60mA per LED (Full White) |
|
Color Resolution |
24-bit (256 levels per channel) |
|
Communication |
Single-wire NZR protocol |
|
Data Transfer Rate |
800 Kbps |
|
Cascade Capability |
Unlimited (Signal reshapes automatically) |
|
Viewing Angle |
120 Degrees |
|
Material |
ABS Base + Epoxy封装 |
|
Waterproof Rating |
IP20 (Indoor Use Only) |
|
Operating Temp. |
-25°C to +80°C |
|
Compatible Platforms |
Arduino, ESP32, Raspberry Pi, SP series controllers |
