True Color Mixing: Features 5050 RGBW 4-in-1 LEDs, adding a dedicated white chip (2700K-6000K) for pure whites and soft pastels, significantly expanding your color palette beyond standard RGB.
High-Density Pixel Mapping: Boasts 96 LEDs and 16 DMX segments per meter, allowing for incredibly smooth text, graphic, and video animations with a fine 62.5mm cuttable resolution.
Professional DMX512 Control: Fully compatible with mainstream lighting consoles (e.g., MA, Avolites) via standard XLR or screw terminals, supporting 16-bit dimming and high refresh rates (>2000Hz) for flicker-free camera operation.
Stable 24V Power System: Operates on DC24V with a 2oz thick copper FPCB, minimizing voltage drop and allowing a single power feed to run up to 5 meters of continuous light reliably.
Versatile & Durable Build: Housed in a flexible 12mm wide PCB with 3M adhesive backing. Choose from IP20 (indoor), IP65 (splash-proof), or IP67 (outdoor waterproof) to suit any installation environment.
Product: DMX512 RGBW LED Pixel Tape
Model: DMX-5050-RGBW-16S-96D-24V
|
Parameter |
Specification |
|---|---|
|
LED Type |
SMD 5050 RGBW (4-in-1) |
|
LED Density |
96 LEDs / Meter |
|
DMX Segments |
16 Segments / Meter (1 IC per 6 LEDs) |
|
Voltage |
DC 24V |
|
Power |
23W / Meter (Max) |
|
PCB Width |
12mm |
|
Cutting Unit |
Every 6 LEDs (62.5mm) |
|
Grayscale |
16-bit (65536 levels) |
|
Refresh Rate |
>2000 Hz |
|
Signal Protocol |
Standard DMX512 (XLR/ Screw Terminal) |
|
IP Rating |
IP20 / IP65 / IP67 Optional |
|
Beam Angle |
120° |
