Brighter than 2835 pixel tapes and more stable than 5V/12V long strips, it’s a solid choice for contractors, OEMs, and premium decorative lighting.
24V Long-Distance Design: less voltage drop than 12V/5V strips, better for 5–10m+ runs.
UCS1903B Addressable: 12 pixels/m, 1 IC drives 6×5050 RGB, smooth full-color effects.
High-Brightness 5050 RGB: strong output for outdoor signage, facade, stage, and retail.
10mm Robust FPC: easy in aluminum profiles / light boxes; 2oz copper optional.
Cut & Cascade: cut every 6 LEDs (≈83.3mm), DIN→DOUT cascade, SPI/UCS1903B controller.
|
Item |
Specification |
|---|---|
|
Model |
UCS1903B-5050RGB-72D-24V-10mm |
|
LED Type |
SMD 5050 RGB |
|
IC Type |
UCS1903B (SPI, external IC) |
|
Input Voltage |
DC 24V |
|
LED Density |
72 LEDs/m |
|
Pixel Density |
12 pixels/m (6 LEDs / pixel) |
|
Cutting Unit |
6 LEDs ≈ 83.3 mm |
|
PCB Width |
10 mm FPC |
|
Power |
≈ 17.3 W/m (typ. 16–18 W/m) |
|
Current |
≈ 0.72 A/m @ 24V |
|
Gray Scale |
8-bit × 3CH (256/CH) |
|
Signal Interface |
3-pin: VCC / GND / DIN (DOUT cascade) |
|
Controller |
UCS1903B / SPI addressable controller |
|
Beam Angle |
120° |
|
PCB Color |
White / Black |
|
IP Rating |
IP20 bare board (IP65/IP67/IP68 optional) |
|
Length |
5 m/reel |
|
Life Span |
30,000 h+ |
|
Application |
Building outline, signage, mall decor, stage, bridge, commercial facade |
