Built with premium internal components, it offers comprehensive protection against short circuits, overloads, and over-voltage, ensuring the safety of your valuable devices. Its compact, slim-profile design allows for easy installation in tight spaces, while the universal AC input (110V/220V) makes it globally compatible. Upgrade your setup with a power supply that combines industrial-grade reliability, silent operation, and exceptional efficiency.
Ultra-Silent Fanless Design: Utilizes a high-quality aluminum shell for natural convection cooling, providing zero noise operation, perfect for living rooms, studios, and offices.
High-Current Output: Delivers a robust and stable 5V DC output at 60A, providing 300W of continuous power for demanding electronic projects and industrial loads.
Comprehensive Safety Protection: Features built-in safeguards including Short Circuit, Overload, Over-Voltage, and Over-Temperature Protection to ensure maximum reliability and safety for your devices.
Universal Input & High Efficiency: Supports a wide AC input range (110V/220V) with active PFC, achieving high energy conversion efficiency while reducing heat generation.
Durable & Compact Structure: The rugged metal casing resists electromagnetic interference (EMI) and physical impact, while the slim, elongated form factor allows for easy installation in narrow spaces.
|
Category |
Specification |
|---|---|
|
Product Model |
SPS-300-5 (Fanless) |
|
Output Power |
300W Max |
|
DC Output |
5V |
|
Output Current |
0 ~ 60A |
|
Voltage Adjustability |
±10% (4.5V ~ 5.6V) |
|
Input Voltage |
110V/220V AC (Selectable) / 90~132VAC or 176~264VAC |
|
Frequency |
47 ~ 63 Hz |
|
Efficiency |
82% (Typical) |
|
Ripple & Noise |
≤ 150mVp-p |
|
Load Regulation |
±1.0% |
|
Line Regulation |
±0.5% |
|
Cooling Method |
Natural Convection (Fanless) |
|
Protection |
Short Circuit / Overload / Over Voltage / Over Temp |
|
Operating Temp. |
-10°C to +50°C (Derating may apply above 40°C) |
|
Safety Standards |
CE, RoHS, FCC |
|
Dielectric Strength |
I/P-O/P: 1.5KV AC, I/P-FG: 1.5KV AC |
|
Dimensions (LxWxH) |
215 x 115 x 50 mm (Approx.) |
|
Applications |
LED Strip Lighting, CCTV Systems, 3D Printers, Industrial Control |
