This 24V 2835 single-color strip features 120 LEDs per meter on a standard 10mm PCB—the sweet spot for brightness, heat dissipation and cost. The 2835 chip delivers excellent efficacy and reliable output, while 24V keeps current low and voltage drop minimal for runs up to 10m per feed. Available in 2700K/3000K/4000K/6000K with CRI≥80 or ≥90. Cut every 6 LEDs (50mm), 3M adhesive, flexible and installer-friendly. Ideal for kitchens, offices, retail shelves, coves, corridors and any space needing clean, even white light. Pair with aluminum profiles for a premium dot-free finish.
120 LEDs/m Balanced Density: Smooth, uniform light without overdriving individual LEDs—optimal brightness-to-lifespan ratio.
10mm Standard PCB: Better heat dissipation than 6mm/8mm narrow strips; supports higher drive current for max brightness.
24V Efficient Power: Lower current draw than 12V equivalents, less voltage drop, longer runs from a single power feed.
Proven 2835 Reliability: Mature chip platform, high lm/W, low failure rate, consistent color binning.
Versatile Install: Cut every 50mm, 3M backing, IP20/IP65/IP67 options, compatible with PWM/0-10V/Triac dimmers (with driver).
|
Item |
Specification |
|---|---|
|
LED Type |
SMD 2835 (single chip, 2.8×3.5mm) |
|
Color |
Single Color: 2700K / 3000K / 4000K / 6000K |
|
LED Density |
120 LEDs/m |
|
Voltage |
DC 24V |
|
Power |
~9.6–12 W/m (typical), ~14.4 W/m max |
|
Cut Unit |
Every 6 LEDs / 50 mm |
|
PCB Width |
10 mm |
|
CRI |
Ra ≥80 / Ra ≥90 optional |
|
Lumen |
~900–1200 lm/m (depends on CCT) |
|
Beam Angle |
120° |
|
Dimming |
PWM / 0-10V / Triac (with driver) |
|
IP Rating |
IP20 / IP65 / IP67 optional |
|
Adhesive |
3M tape |
|
Working Temp. |
-20°C ~ +60°C |
|
Lifespan |
30,000–50,000 hrs |
|
Note |
Non-addressable; uniform single-color output |
