1. Ultra-High Density & Dot-Free Glow
Features 240 LEDs per meter using 2835 SMD chips on a slim 8mm PCB. The high density ensures perfectly uniform, dot-free linear lighting—ideal for premium architectural and interior applications.
2. Adjustable Dual Color Temperature (CCT)
Easily switch between warm white (2700K) and cool white (6500K) to match any mood or task. Enjoy cozy ambiance for relaxing or bright daylight for focused work, all from one versatile strip.
3. Stable & Safe 24V Low Voltage
Powered by DC 24V for consistent, flicker-free performance with minimal voltage drop. The low-voltage design is safe to touch and energy-efficient at 24W/m—perfect for long-term daily use.
4. 3-Wire Single Row, Flexible & Slim
The compact 3-wire single-row layout keeps the profile ultra-thin and flexible. Easily bend and cut the strip to fit tight spaces like cabinets, shelves, staircases, and display cases.
5. Versatile Indoor Applications
Equipped with strong backing adhesive for quick peel-and-stick installation. Perfect for kitchen counters, bedroom accents, living room coves, retail displays, and office lighting upgrades.
Product Specification Sheet
Product Name: 24V Dual Color Temperature LED Strip Light
|
Item |
Specification |
|---|---|
|
Model |
2835-240D-3W-CCT |
|
LED Type |
SMD 2835 |
|
LED Density |
240 LEDs/meter |
|
Color Temperature |
2700K – 6500K Adjustable (CCT) |
|
Input Voltage |
DC 24V |
|
Power Consumption |
24W/m |
|
PCB Width |
8mm |
|
Wiring |
3-Wire (Single Row) |
|
Beam Angle |
120° |
|
CRI |
≥90 (typical) |
|
Cuttable Unit |
Every 6 LEDs (25mm) |
|
Adhesive |
3M Backing Tape |
|
Operating Temp. |
-20°C to +50°C |
|
IP Rating |
IP20 (Non-waterproof, custom options available) |
|
Lifespan |
≥50,000 hours |
|
Certifications |
CE / RoHS (optional per batch) |
|
Warranty |
3 Years |
Package Includes: LED Strip Roll (5m/10m/16.4ft per roll, customizable), Installation Guide.
Key Features Summary:
High-density 240 LEDs/m for dot-free, uniform illumination
Seamless CCT tuning from warm 2700K to cool 6500K
Slim 8mm PCB fits narrow profiles and tight spaces
3-wire single-row design for clean, flexible installation
Stable 24V operation with low heat and minimal voltage drop
Typical Applications: Kitchen cabinet lighting, bedroom accent, living room cove, retail display, office task lighting, hotel and hospitality decor.
Ordering Information:
|
Part No. |
CCT Range |
Voltage |
Power |
PCB Width |
Roll Length |
|---|---|---|---|---|---|
|
S24-2835-240-3W-8C |
2700K–6500K |
24V |
24W/m |
8mm |
5m / 10m / Custom |
