Powered by a stable 5V system and featuring the built-in WS2812B IC, each LED is individually addressable, enabling you to create dynamic chasing, gradient, and breathing effects with pure white illumination. Despite its high density, the strip remains highly flexible and cuttable every 8.33mm. Please note that due to the high power draw (36W/m max), proper heat dissipation using aluminum profiles and dual-end power injection is required for optimal performance. Perfect for professional signage, display cases, and creative DIY projects demanding high brightness and reliability.
Ultra-Narrow & High Density: Features a 5mm wide flexible PCB with 120 LEDs per meter, ensuring seamless linear lighting and easy installation in confined spaces.
Individually Addressable: Integrated WS2812B IC allows for programmable control of each LED, enabling dynamic white flowing, chasing, and gradient effects.
Superior Brightness & Uniformity: Utilizes high-efficiency 3535 LEDs to produce consistent, high-lumen white light without visible hotspots.
Precision Cuttable: Designed for custom fits with a cut-point every 8.33mm (single LED), maintaining circuit integrity for detailed projects.
Wide Compatibility: Supports standard 5V logic levels, making it compatible with Arduino, Raspberry Pi, ESP32, and mainstream SPI/MCU controllers.
|
Parameter |
Specification |
|---|---|
|
Product Model |
WS2812B-3535-120-5mm |
|
LED Type |
WS2812B (Built-in IC), 3535 SMD |
|
Color |
Digital White (Flowing Effect) |
|
LED Density |
120 LEDs/meter |
|
Strip Width |
5mm (FPCB) |
|
Operating Voltage |
DC 5V |
|
Power Consumption |
36W/meter (Max) |
|
Control Protocol |
Single-wire Return-to-Zero (800Kbps) |
|
Gray Scale |
256 levels per channel (24-bit color) |
|
Cutting Unit |
Every 1 LED (8.33mm) |
|
Beam Angle |
120° |
|
IP Rating |
IP20 (Non-waterproof) / IP65 Optional |
|
Operating Temp. |
-20°C to +50°C |
|
Recommended Use |
Indoor signage, display lighting, DIY projects |
