210lm/W Breakthrough Efficacy: Industry-leading luminous efficiency delivers maximum brightness from minimal power—slashing energy costs to the absolute minimum.
Ultra-Low 4.3W/m Power Draw: Runs exceptionally cool; ideal for battery-powered, solar, and heat-sensitive installations with little to no heatsink required.
90 LEDs/m Uniform Layout: Provides smooth, even light output without hotspots—perfect for subtle cove, stair, and accent lighting.
Stable DC24V Constant Voltage: Reliable long-run performance with minimal voltage drop; safe low-voltage operation for all environments.
Flexible & Easy to Install: Cut every 100mm (9 LEDs) for quick customization; compatible with PWM, 0-10V, and DALI dimming systems.
|
Item |
Specification |
|---|---|
|
Product Name |
Ultra-Eco High-Efficiency 2835 LED Strip Light |
|
LED Type |
SMD 2835 |
|
LED Density |
90 LEDs/meter |
|
Working Voltage |
DC 24V Constant Voltage |
|
Power Consumption |
4.3W/meter (max. rated) |
|
Luminous Efficacy |
210 lm/W (LED/module level) |
|
Luminous Flux |
Approx. 903 lm/m (theoretical max.) |
|
Color Rendering Index |
Ra80 |
|
Color Temperature |
2700K / 3000K / 4000K / 5700K / 6500K (optional) |
|
Cutting Unit |
Every 100mm (9 LEDs) |
|
PCB Width |
8mm / 10mm (optional) |
|
Roll Length |
5 meters/reel |
|
IP Rating |
IP20 / IP65 / IP66 / IP68 (optional) |
|
Dimming |
PWM / 0-10V / DALI compatible |
|
Recommended Driver |
24V CV LED power supply (20–30% power margin) |
|
Heat Dissipation |
Minimal required; aluminum profile optional |
|
Applications |
Emergency lighting, solar-powered systems, battery backup, stair & step, subtle cove, eco-building projects |
|
Warranty |
3–5 years (varies by supplier) |
