Engineered for extreme-output applications, the 24V constant voltage platform demands heavy-duty aluminum profiles and high-capacity drivers. Cuttable every 50mm for precision. The ultimate fusion of maximum density, maximum efficiency, and maximum brightness for high-end retail, museum, and architectural masterpieces.
Extreme 480 LEDs/m Density: 2× the density of standard flagship strips—produces perfectly continuous light without a single visible hot spot, even direct-view.
8775 lm/m Massive Output: Highest brightness-to-density ratio in the lineup; floods large spaces with uniform, glare-free illumination.
195lm/W Top-Tier Efficacy: Extracts maximum lumens from every watt at 45W/m; reduces energy waste vs. lower-efficacy high-power competitors.
Selectable CRI (Ra80/90/95): Museum-grade Ra95 available for color-critical installations; Ra80 keeps budget in check for functional high-output needs.
50mm Precision Cut & Fully Dimmable: Cut every 50mm (24 LEDs) for exact layout; compatible with PWM, 0-10V, and DALI protocols.
|
Item |
Specification |
|---|---|
|
Product Name |
Super-Density High-Output 2835 LED Strip Light |
|
LED Type |
SMD 2835 (High-Efficiency Bin) |
|
LED Density |
480 LEDs/meter |
|
Working Voltage |
DC 24V Constant Voltage |
|
Power Consumption |
45W/meter (max. rated) |
|
Luminous Efficacy |
195 lm/W (LED/module level) |
|
Luminous Flux |
8775 lm/m (rated output) |
|
Color Rendering Index |
Ra80 / Ra90 / Ra95 (selectable) |
|
Color Temperature |
2700K / 3000K / 4000K / 5000K / 5700K / 6500K (optional) |
|
Cutting Unit |
Every 50mm (24 LEDs) |
|
PCB Width |
15mm / 20mm (3oz copper standard) |
|
Roll Length |
5 meters/reel (max. 1.5–2m continuous recommended per feed) |
|
IP Rating |
IP20 / IP65 / IP66 / IP68 (optional) |
|
Dimming |
PWM / 0-10V / DALI compatible |
|
Recommended Driver |
24V CV high-capacity power supply (30% power margin minimum) |
|
Heat Dissipation |
Required — heavy-duty aluminum profile with thermal transfer tape; active cooling recommended for enclosed fixtures |
|
Wiring |
18AWG minimum; parallel feed recommended every 1.5m |
|
Applications |
High-end retail flagship, museum & gallery, studio lighting, architectural flood, large cove, industrial high-bay |
|
Warranty |
3–5 years (varies by supplier) |
