Featuring 8 independent output ports, it supports a vast library of IC chips including WS2811, WS2812B, and SK6812. The built-in OLED display and intuitive buttons allow for quick on-site configuration without a computer.
What sets it apart is its versatility. Use it for real-time control via Madrix or MadMapper, or record your shows to the SD card for offline, standalone playback. The device supports multi-controller synchronization, making it perfect for large-scale architectural and stage installations. With a wide voltage input (DC5-24V) and robust aluminum casing, the ArtNet-SPI-8 delivers professional-grade reliability and performance for any pixel lighting project.
High-Capacity Processing: Supports up to 8 Art-Net Universes and 1,360 pixels, ensuring smooth data output for complex lighting displays.
Wide IC Compatibility: Pre-configured to support 40+ IC types (WS2811, WS2812B, SK6812, etc.), easily switchable via the OLED menu.
Dual Operation Modes: Seamlessly switch between Real-time Control (via PC software) and Standalone Playback (via SD card).
Multi-Device Synchronization: Built-in timing function allows multiple units to run in perfect sync without a master controller.
Professional & Robust: Features wide voltage input (5-24V), RJ45 Ethernet port, and a durable housing designed for -30°C to 55°C environments.
|
Category |
Specification |
|---|---|
|
Product Model |
ArtNet-SPI-8 |
|
Input Signal |
Art-Net (Ethernet) |
|
Output Signal |
SPI (TTL Level) |
|
Control Capacity |
8 Universes / 1,360 Pixels (Max) |
|
Output Ports |
8 Ports (Configurable) |
|
Power Supply |
DC 5V – 24V |
|
Power Consumption |
< 1.5W |
|
Supported ICs |
WS2811, WS2812B, SK6812, SM16703, TM1812, etc. |
|
Display |
OLED Display with 4-Key Navigation |
|
Storage |
SD Card Slot (Up to 8GB) |
|
Network Protocol |
Art-Net (Standard UDP) |
|
Working Temp. |
-30°C to +55°C |
|
Dimensions |
170mm (L) × 90mm (W) × 25mm (H) |
|
Software Support |
MADRIX, MadMapper, JINX!, xLights |
