Massive 3960 lm/m Output: Highest total brightness in the 180lm/W tier—dominates large-scale architectural and retail lighting with ease.
Ultra-High 240 LEDs/m Density: Completely dot-free, continuous light line even in shallow diffusers; perfect for close-proximity viewing and premium installations.
Selectable CRI (Ra80/90/95): Scalable color quality on one platform—from cost-effective commercial to museum-grade rendering.
Stable DC24V Constant Voltage: Low voltage drop ensures consistent brightness over 5m+ runs; safe low-voltage operation for all environments.
Ultra-Precision 25mm Cut & Fully Dimmable: Cut every 25mm (6 LEDs) for exact length matching; compatible with PWM, 0-10V, and DALI systems.
|
Item |
Specification |
|---|---|
|
Product Name |
Flagship Ultra-High Density 2835 LED Strip Light |
|
LED Type |
SMD 2835 |
|
LED Density |
240 LEDs/meter |
|
Working Voltage |
DC 24V Constant Voltage |
|
Power Consumption |
22W/meter (max. rated) |
|
Luminous Efficacy |
180 lm/W (LED/module level) |
|
Luminous Flux |
3960 lm/m (rated output) |
|
Color Rendering Index |
Ra80 / Ra90 / Ra95 (selectable) |
|
Color Temperature |
2700K / 3000K / 4000K / 5700K / 6500K (optional) |
|
Cutting Unit |
Every 25mm (6 LEDs) |
|
PCB Width |
12mm / 15mm (optional) |
|
Roll Length |
5 meters/reel |
|
IP Rating |
IP20 / IP65 / IP66 / IP68 (optional) |
|
Dimming |
PWM / 0-10V / DALI compatible |
|
Recommended Driver |
24V CV LED power supply (20–30% power margin) |
|
Heat Dissipation |
Required with aluminum profiles (22W/m thermal load) |
|
Applications |
Flagship retail, luxury hotel, high-end cove, museum, architectural flood, shallow profile linear fixtures |
|
Warranty |
3–5 years (varies by supplier) |
