Its intuitive digital display and buttons allow for quick address and baud rate configuration without extra software. With 30 customizable command slots and support for high-speed SPI output, the M-220 offers unmatched flexibility. Built for reliability with wide voltage input (DC 9-24V), it is the ideal tool for integrators needing to unify different control systems or upgrade legacy fixtures to modern DMX control. Simplify your signal flow and expand your creative possibilities with this compact yet powerful converter.
Multi-Protocol Conversion: Effortlessly converts DMX512 signals to RS485, RS232, or SPI (TTL) to control various lighting fixtures and LED strips.
5 Flexible Working Modes: Supports d2C (Custom CMD), d2U (Built-in CMD), r2d (RS485 to DMX), d2r (DMX to RS485), and SPI (Direct LED driving).
Customizable Command Library: Store up to 30 groups of user-defined RS485 commands triggered by specific DMX channel values for advanced automation.
Wide Compatibility & High Speed: Supports multiple SPI chipsets (WS2812, 2811, TM1814) and adjustable baud rates up to 256,000 bps for fast data transmission.
Easy Configuration: Features a clear digital tube display and physical keys for standalone setup; supports USB connectivity for firmware updates and command downloading.
|
Feature |
Specification |
|---|---|
|
Model |
M-220 |
|
Input Signal |
DMX512 (Standard XLR/RJ45) |
|
Output Signal |
RS485 / RS232 / SPI (TTL) |
|
Power Supply |
DC 9V - 24V (Recommended >0.5A) |
|
DMX Channels |
512 Channels (Configurable Start Address) |
|
SPI Pixels |
Max 170 pixels (RGB) / 128 pixels (RGBW) |
|
Baud Rate |
9600 - 256000 bps (Mode Dependent) |
|
Custom Commands |
30 Groups (Max 15 bytes per group) |
|
Display |
3-Digit Digital Tube |
|
Dimensions |
Compact size for rail or cabinet mounting |
