1. Advanced Pixel Control with UCS512H4 Chip
Features the high-performance UCS512H4 IC for seamless DMX512 signal transmission. Enjoy precise, flicker-free control over each individual pixel, enabling the creation of dynamic, synchronized lighting effects for professional displays.
2. Soft & Uniform Diffuse Reflection
Engineered with a specialized diffuse reflection lens, this block light delivers ultra-soft, glare-free illumination. It effectively eliminates harsh shadows and bright spots, making it ideal for high-end signage and architectural lighting where visual comfort is key.
3. Dual Color Temperature Flexibility
Easily switch between warm and cool white tones to match any ambiance. Whether you need cozy, inviting warmth or crisp, professional coolness, this module provides versatile color temperature adjustment to suit diverse applications.
4. High-Quality 2835 LEDs & Stable 24V Operation
Equipped with 6 premium 2835 SMD LEDs per module, running on a stable DC24V system. This ensures low voltage drop, high luminous efficiency (5.9W max), and consistent brightness across your entire installation, even in large-scale setups.
5. Modular Design for Easy Installation
Compact 68x68mm size with a convenient 20-piece-per-group configuration. The modular structure allows for quick, tool-free assembly and flexible layout options, saving you time and labor costs during installation.
Product Specification Sheet
Product Name: DMX512 Dual Color Temperature Diffuse Reflection Block Light
Model: UCS512H4-24V-Dual-CCT
Control IC: UCS512H4
Signal Protocol: DMX512
Electrical Parameters
• Input Voltage: DC24V
• Max Power Consumption: 5.9W / piece
• Pixel Configuration: 1 pixel / piece
• Group Configuration: 20 pieces / group
Optical Parameters
• LED Type: 2835 SMD
• LED Quantity: 6 LEDs / piece
• Color Temperature: Dual Color Temperature (Tunable White)
• Beam Effect: Diffuse Reflection (Soft, Glare-Free)
Physical Parameters
• Dimensions: 68 × 68 mm
• Ingress Protection: IP20 (Indoor Use)
• Installation: Modular assembly, easy snap-in design
Applications
Ideal for indoor signage, architectural accents, decorative lighting, commercial displays, and custom DMX lighting projects.
Key Features
• Seamless DMX512 pixel control
• Uniform light distribution via diffuse reflection lens
• Stable 24V low-voltage operation
• Compact form factor for flexible layouts
