High-density 5V pixel tape with the most common addressable IC. This DC5V SK6812 5050 RGB strip has 96 LEDs per meter, each with a built-in SK6812 controller—every LED is one pixel, individually addressable for chase, gradient, rainbow, and text effects. It uses the classic 3-wire setup: 5V, GND, DIN, and is fully WS2812B/NeoPixel compatible, so it talks to Arduino, ESP32/WLED, Raspberry Pi, K-1000C, T-1000C, and SPI/DMX decoders out of the box. 96/m gives denser visuals than 60/m while staying cheaper and cooler than 144/m. Because it’s 5V, inject power often on long runs. Perfect for DIY signs, DJ booths, shelf glow, cosplay, and small-stage pixel work.
96 Pixels/m, 1 LED = 1 IC – Dense, smooth pixel effects; brighter/more detailed than 60/m strips.
SK6812 = WS2812B Class – Single-wire NZR protocol, huge library support (FastLED, WLED, Adafruit NeoPixel).
3-Wire Simple – Just 5V / GND / DIN; no clock line, no dual-signal wiring.
5050 RGB High Output – 120° beam, 256 gray/chan, full 24-bit color for rainbows and video pixels.
Maker-Friendly 5V – Arduino, ESP32, Pi Pico, K-1000C, T-1000C, DMX SPI decoder; 10mm FPC fits mini profiles.
|
Parameter |
Specification |
|---|---|
|
Product Type |
Addressable RGB LED strip (single-wire) |
|
LED / IC |
SMD5050 RGB + built-in SK6812 |
|
Voltage |
DC 5V (4.5–5.5V) |
|
LED Density |
96 LEDs/m |
|
Pixel Density |
96 pixels/m (1 LED = 1 pixel) |
|
Wires |
3-wire: +5V / GND / DIN |
|
Protocol |
SK6812 / WS2812B-compatible, 800 kbps NZR |
|
Power |
~14.4 W/m (0.15W/LED) or ~28.8W/m (0.3W/LED) |
|
PCB Width |
10 mm (some 12mm) |
|
Cut Unit |
10.42 mm (1 LED) |
|
Color |
24-bit, 256 gray/chan |
|
Beam Angle |
120° |
|
Roll |
5 m/reel |
|
Controllers |
Arduino/FastLED, ESP32/WLED, Pi Pico, K-1000C, T-1000C, DMX SPI decoder |
|
Breakpoint |
No (single-wire SK6812: one dead pixel can stop the tail) |
|
IP Rating |
IP20 / IP65 / IP67 / IP68 |
|
Life |
30,000–50,000 hrs |
