The 12mm wide FPC ensures excellent heat dissipation and durability, while the DC24V low voltage guarantees safety and stability. Perfect for TV backlighting, under-cabinet, coves, bedrooms, or commercial displays. Cut freely at marked intervals and pair with any RGBCCT controller (not included) to create dynamic scenes or schedule daily automations. Waterproof ratings (IP65/IP67) are available for kitchens, bathrooms, or outdoor use. Experience seamless, professional-grade lighting that transforms any space.
Ultra-High 840 LEDs/m Density: COB technology eliminates light dots, producing a flawless, continuous line of light even at close range.
5-in-1 RGBCCT Full Control: Switch between 16 million RGB colors and tune white from cozy 2700K to crisp 6500K—all from one strip.
Premium 12mm Wide FPC: Extra width improves heat dissipation, reduces voltage drop, and supports higher power output for consistent brightness.
Flexible & Cuttable Design: Cut at precise intervals (e.g., every 35mm/41.7mm depending on batch) to fit any project; bend around curves with ease.
Versatile Application & Safe: Operates on safe DC24V; compatible with RGBCCT controllers for smart control (app/voice/remote). Ideal for residential and commercial spaces, with IP20/IP65/IP67 options.
|
Item |
Specification |
|---|---|
|
Product Name |
COB RGB+CCT LED Strip Light |
|
Model No. |
[Your Model Number] |
|
LED Type |
COB (Chip on Board) RGBCCT |
|
LED Density |
840 chips/meter |
|
PCB Width |
12 mm |
|
Working Voltage |
DC 24V (Constant Voltage) |
|
Power Consumption |
16W/m, 21W/m, 22W/m, or 25W/m (optional) |
|
Color Temperature |
Tunable White 2700K–6500K + Full RGB |
|
CRI (Ra) |
≥90 |
|
Beam Angle |
180° |
|
Cutting Unit |
35mm / 41.7mm / 25mm (varies by production batch) |
|
Max Run Length |
5 meters (single feed); longer runs require parallel wiring |
|
Waterproof Rating |
IP20 (Non-waterproof), IP65 (Silicone coating), IP67 (Silicone tube), IP68 (custom) |
|
Operating Temp. |
-20°C to +45°C |
|
Dimming |
Yes, via RGBCCT controller (PWM) |
|
Installation |
3M adhesive tape on back; recommended to use aluminum profile for heat dissipation |
|
Warranty |
2–3 Years (standard) |
|
Certifications |
CE, RoHS, FCC (optional: UL) |
|
Applications |
Home theater, cabinet, cove, bedroom, hotel, bar, commercial display, architectural outline |
