Whether you need a standalone show using its built-in effects (Master Mode) or precise control via a DMX console (Slave Mode), the BC-820 handles it flawlessly. Built-in safety features like output fuse protection and DMX interface safeguards ensure your installation runs smoothly night after night. Compact, reliable, and versatile, the BC-820 is the professional's choice for stage lighting, architectural façades, and dynamic signage.
(Word count: 130)
Universal Compatibility: Automatically adapts to DC5V-24V inputs and supports a wide range of popular addressable LED ICs (WS2811, WS2812B, SK6812, etc.).
Intuitive LCD Interface: Features a clear LCD menu display for easy configuration of IC type, DMX address, and pixel count, eliminating guesswork.
Dual Operation Modes: Functions as a Slave for DMX console control or as a Master with 26 built-in dynamic programs for standalone applications.
High Capacity Processing: Supports up to 170 RGB pixels or 128 RGBW pixels, handling complex lighting sequences with 510/512 DMX channels.
Robust Protection: Equipped with output fuse over-current protection and DMX interface protection to ensure system safety and longevity.
|
Category |
Specification |
|---|---|
|
Product Model |
BC-820 |
|
Input Signal |
DMX512 / DMX1990 |
|
Output Signal |
SPI (TTL) |
|
Input Voltage |
DC 5V - 24V (Auto-adapting) |
|
Output Current |
5A (Fuse Protected) |
|
DMX Channels |
510 Channels (RGB) / 512 Channels (RGBW) |
|
Max Pixels |
170 Pixels (RGB) / 128 Pixels (RGBW) |
|
Control Modes |
Master Mode (Built-in programs), Slave Mode (DMX Control) |
|
Display |
LCD Menu Display |
|
Supported IC Types |
WS2811, WS2812B, SK6812, WS2801, LPD6803, LPD8806, P9813, TM1814, etc. |
|
Protection Rating |
Output Fuse Over-current Protection, DMX Interface Protection |
|
Dimensions |
176mm (L) × 46mm (W) × 30mm (H) |
|
Weight |
180g |
|
Applications |
Stage Lighting, Architectural Decoration, LED Signs, Pixel Art |
