Packing 480 high-density COB chips into an 8mm flexible PCB, it delivers a smooth, dot-free ribbon of light with CRI 90+ (95+ optional) color accuracy. Dual-voltage design supports both 12V and 24V systems — choose 12V for short cabinet runs or 24V for long cove and architectural installations. At 15W/m (24V), it produces brilliant output while staying cool to the touch. Single LED failure does not affect adjacent chips, eliminating the "dead section" problem of traditional strips. Cut at marked intervals, mount with 3M backing or aluminum profiles. Built for contractors, architects, and installers who can't afford callbacks.
🔄 Built-in Constant Current IC — Uniform Brightness — Every LED node integrates a constant current chip; brightness and CCT stay identical from start to end on long runs (up to 10m+); no voltage-drop dimming, no color shift.
🛡️ Single-Fail-Not-Out Design — If one LED fails, the rest continue operating normally; no dark zones, no cascading failure — dramatically reduces maintenance and callback costs on commercial projects.
✨ 480 COB LEDs & Dot-Free Output — High-density COB chips produce a continuous, seamless line of light with zero hotspots; 8mm slim profile fits standard narrow aluminum channels.
⚡ Dual Voltage 12V/24V Auto-Adapt — Works with both 12V and 24V drivers; 12V for short runs (<3m), 24V for long runs (3–10m+) with minimal voltage drop; 15W/m (24V) high brightness output.
🏗️ Engineering Grade & Cuttable — 2oz copper FPCB, 3M VHB backing, cut at marked intervals; compatible with standard dimmers and controllers; IP20/IP65 optional; rated for continuous commercial operation.
|
Specification |
Details |
|---|---|
|
Product Name |
COB Constant Current LED Strip Light |
|
Model |
COB-CC-8MM-12V24V-480D |
|
Strip Width |
8mm |
|
LED Type |
COB with embedded constant current IC (per-node) |
|
LED Density |
480 LEDs/m |
|
Operating Voltage |
DC 12V / DC 24V (auto-adapt, dual voltage) |
|
Power Consumption |
12V: ~8W/m; 24V: ~15W/m |
|
Color Temperature |
2700K / 3000K / 4000K / 5000K / 6000K |
|
CRI Options |
Ra ≥ 90 / Ra ≥ 95 / Ra ≥ 97 |
|
Luminous Flux |
12V: ~700–800 lm/m; 24V: ~1300–1500 lm/m |
|
Brightness Uniformity |
±3% over 10m run (24V) |
|
CCT Shift |
< 200K over full length |
|
Dimming |
PWM 0–100% (flicker-free) |
|
Single-Fail Mode |
Fail-not-out; adjacent LEDs unaffected |
|
Beam Angle |
180° |
|
Cuttable Unit |
12V: every 25mm; 24V: every 50mm |
|
PCB Material |
2oz copper flexible FPCB |
|
Adhesive |
3M VHB tape backing |
|
IP Rating |
IP20 (standard) / IP65 (silicone coating) / IP67 (hollow tube) |
|
Working Temp. |
-20°C ~ +55°C |
|
Lifespan |
≥ 50,000 hours |
|
Certifications |
CE, RoHS, LM-80 |
|
Warranty |
3 Years (engineering grade) |
|
Applications |
Commercial cove, cabinet, shelf, architectural slot, hotel, office, retail, display, linear pendant |
|
Target Users |
Contractors, installers, architects, lighting designers, distributors |
