1. 【Ultra-High Density COB Design】
Features 840 LEDs/m with advanced COB technology, delivering a completely uniform, dot-free linear glow. Perfect for high-end architectural lighting and seamless ambient decor without any visible hotspots.
2. 【WS2811F External IC & SPI Control】
Equipped with an external WS2811F chip and high-speed SPI signal transmission, ensuring stable data and precise pixel control. Supports individual addressable effects and dynamic dream-color chasing for creative lighting designs.
3. 【5-in-1 RGBCCT Full Color】
Integrates RGB + Cool White + Warm White in one strip, allowing you to switch freely between 16 million vibrant colors and tunable white (CCT 2700K-6500K). One strip meets all your colorful and functional lighting needs.
4. 【Professional 24V & High Power Output】
Operates on 24V DC with 29W/m high power and a 12mm wide PCB for excellent heat dissipation. 24V ensures low voltage drop, making it ideal for long-run commercial installations and large-scale projects.
5. 【Versatile Applications & Easy Setup】
Comes with 24 pixels/m and can be cut per pixel unit. Compatible with popular SPI controllers (e.g., SP107E, K1000C). Ideal for DIY gaming setups, home theaters, bars, hotels, and stage backdrops.
Product Name: 24V COB RGBBCCT Addressable LED Strip Light
Model: WS2811F-COB-840-24V
|
Parameter |
Specification |
|---|---|
|
Input Voltage |
DC 24V |
|
Power Consumption |
29W/m (Max) |
|
LED Type |
COB (Chip on Board) |
|
LED Density |
840 LEDs/m |
|
IC Type |
WS2811F (External IC) |
|
Signal Protocol |
SPI |
|
Color Mode |
RGBCCT (RGB + Cool White + Warm White) |
|
Pixels |
24 Pixels/m |
|
PCB Width |
12mm |
|
Cuttable Unit |
Per Pixel (Addressable) |
|
Beam Angle |
180° (Dot-free uniform glow) |
|
IP Rating |
IP20 / IP65 / IP67 (Optional) |
|
Working Temp. |
-20°C to +50°C |
|
Lifespan |
≥50,000 hours |
|
Compatible Controllers |
SP107E, K1000C, Arduino, Raspberry Pi, etc. |
|
Applications |
Architectural lighting, home decor, gaming setups, bars, hotels, stage backdrops |
Key Features Summary:
✅ Ultra-High Density: 840 LEDs/m COB design for seamless, dot-free illumination
✅ External IC Stability: WS2811F + SPI ensures fast signal transmission and precise pixel control
✅ 5-in-1 Full Color: RGB + CCT tunable white (2700K–6500K), 16 million+ colors
✅ Professional Grade: 24V low voltage drop, 29W/m high brightness, 12mm PCB for heat dissipation
✅ Easy Installation: Cuttable per pixel, flexible FPCB, compatible with mainstream SPI controllers
⚠️ Notes:
Please use a suitable 24V power supply with at least 20% power margin.
A dedicated SPI controller is required for addressable functions (not included).
For long runs, proper heat dissipation and voltage injection are recommended.
