Features
1. Meet DMX512/1990, RDM/2009 international standard protocol
2. 4 output channels, output current 200 to 1600mA per channel
3. Can easily set DMX address by button
4. Can easily set output current each channel
5. With the light color selected mechanism, and be able to control the light with 1~4 colors
6. 8 Bit/16 Bit level brightness, full-color control
7. For customer setup and use easily, the default address code is 1
8. Address setting become brightness setting when DMX signal isn’t connected
9. Suitable for buildings, hotels, KTV, home and other places
10. Flicker-free
Technical Parameters
| Channels | 4 channels |
| Input Voltage | 12-50V DC |
| Output Voltage | 1-42V DC |
| Output Current | 200 to 1600mA per channel |
| Output Power | 67W / CH MAX.240W |
| Protection | Short-circuit protect, Over current protect |
| Pack Size | 135(L)×69(W)×36(H) mm |
| N.G. | 352g |
| Operation Temperature | -20~50℃ |
