The DC24V constant voltage platform ensures stable performance on standard 5m runs, while the 35.7mm cutting interval allows precise length customization. Built on a 10–12mm PCB with 2–3OZ copper, it balances heat dissipation and flexibility. Compatible with most 24V drivers and dimming systems. A versatile, high-value solution for cove lighting, display cases, cabinet lighting, and architectural accents.
Ultra-High 224LEDs/m Density: Near-dot-free light output at 224 LEDs per meter—smooth, continuous illumination even at close viewing distances or without a diffuser.
Balanced 20W/M Performance: 2,900LM/M brightness at moderate power draw; ideal for main or accent lighting without the thermal demands of 50W+ strips.
Versatile CRI Selection: Ra80 for cost-effective commercial installs, Ra90 for retail and hospitality, Ra95 for galleries and color-critical environments.
Precision 35.7mm Cut Points: Short 8-LED cutting intervals enable exact length matching for tight spaces, signage, and custom fixtures.
Stable 24V Platform: DC24V constant voltage with low voltage drop; compatible with standard 24V drivers, PWM dimmers, and smart controls.
|
Item |
Specification |
|---|---|
|
Product Name |
High Density 224LEDs/m LED Strip Light |
|
LED Type |
SMD 2835 |
|
LED Density |
224 LEDs/meter |
|
Drive Type |
Constant Voltage |
|
Working Voltage |
DC 24V |
|
Power Consumption |
20W/Meter |
|
Luminous Flux |
2,900 LM/Meter (4000K, Ra80) |
|
Luminous Efficacy |
145 LM/W |
|
Color Rendering Index (CRI) |
Ra80 / Ra90 / Ra95 Optional |
|
Color Temperature (CCT)** |
2700K / 3000K / 3500K / 4000K / 5000K / 6500K |
|
Beam Angle |
120° |
|
Cutting Unit |
35.7 mm (8 LEDs per cut) |
|
PCB Width |
10 mm / 12 mm |
|
PCB Copper Thickness |
2 OZ / 3 OZ Optional |
|
IP Rating |
IP20 (Non-waterproof) / IP65 Optional |
|
Max Recommended Run |
5m per feed (parallel for longer) |
|
Lifespan |
50,000 Hours |
|
Certification |
CE, RoHS, ERP Compliant |
|
Warranty |
3 Years |
