1. High-Density Pixel Display
Features 160 SK6812 2121 SMD LEDs per meter, delivering ultra-smooth, gradient lighting effects and eliminating visible dotting for a truly seamless visual experience.
2. Ultra-Narrow & Flexible Design
Built with a 6mm narrow PCB, this strip easily fits into tight spaces, narrow aluminum profiles, and complex corners. The flexible FPCB allows for creative bending and shaping without damage.
3. Built-in IC for SPI Control
Each LED integrates a SK6812 driver chip, enabling individual addressability via SPI protocol. Create stunning dream color effects, chasing patterns, and dynamic animations with compatible controllers.
4. Stable 12V Operation
Operates on DC12V with low heat generation and 4.8W/m power consumption. The 12V design minimizes voltage drop, allowing for longer single-run lengths compared to 5V strips.
5. Versatile Applications
Perfect for ambient lighting, gaming PC builds, TV backlighting, architectural accents, and DIY projects. Cuttable every 35mm (every LED) for custom lengths, with 3M adhesive backing for easy installation.
Product Name: 12V SK6812 2121 RGB Addressable LED Strip
|
Item |
Specification |
|---|---|
|
LED Type |
SMD 2121 RGB |
|
IC Type |
SK6812 (Built-in) |
|
LED Density |
160 LEDs / 160 Pixels per meter |
|
PCB Width |
6mm (Narrow Board) |
|
Input Voltage |
DC 12V |
|
Power Consumption |
4.8W / meter (Max) |
|
Control Protocol |
SPI (Single-wire) |
|
Cutting Unit |
Every 35mm (1 LED per cut) |
|
Beam Angle |
120° |
|
IP Rating |
IP20 Non-waterproof (IP65/IP67 optional) |
|
Operating Temp. |
-20°C to +60°C |
|
Length per Roll |
5 Meters (16.4ft) |
|
Adhesive |
3M VHB Tape on back |
Individual Addressable: Each pixel can be controlled separately for dynamic chasing and dream color effects.
High Density: 160 pixels/m provides ultra-smooth color gradients without visible dots.
Flexible & Narrow: 6mm PCB fits into tight profiles and narrow aluminum channels.
Easy Installation: Cuttable design and pre-applied 3M tape for tool-free mounting.
1 x 1M LED Strip Roll
Controller and Power Supply not included
