Engineered on a durable black PCB with onboard filtering capacitors, this pixel matrix ensures stable signal integrity and consistent brightness. Perfect for LED neon signs, commercial displays, architectural lighting, gaming setups, and DIY electronics. Compatible with popular controllers (Arduino, ESP32, Raspberry Pi) and WS2812B-style protocols. Whether you're building a pixel screen, running text display, or ambient backlighting, this module delivers professional-grade visuals in a miniature form factor. Easy to install, highly reliable, and endlessly customizable.
Individually Addressable Pixels — Every LED features a built-in IC chip, allowing independent color and brightness control per pixel for unlimited creative effects.
Ultra-Compact 0807 Package — Measuring just ~2.0×1.7mm per LED, this module fits tight spaces where standard 5050 or 3535 pixels are too bulky.
Cascadable & Scalable — IN/OUT terminal design supports daisy-chain connection of multiple modules to build large video walls or extended pixel strips.
Full-Color 16.7M Display — 256-level grayscale per channel (R/G/B) delivers smooth gradients, vivid animations, and professional-grade color rendering.
Wide Compatibility & Easy Control — Works with Arduino, ESP32, Raspberry Pi, and mainstream LED controllers using single-wire zero-code protocol (WS2812B compatible).
|
Parameter |
Specification |
|---|---|
|
LED Type |
0807 SMD RGB with Built-in IC |
|
IC Compatibility |
WS2812B / similar single-wire protocol |
|
Operating Voltage |
DC 5V (tolerance 3.5V–5.5V) |
|
Color Depth |
24-bit (256 levels × R/G/B), 16.7 million colors |
|
Gray Scale |
256 levels per channel |
|
Data Interface |
Single-wire serial (DIN / DOUT) |
|
Cascading |
Supported via IN/OUT terminals |
|
PCB Color |
Black |
|
Module Dimensions |
[Insert actual L×W×H, e.g., 120×15×2mm]* |
|
Pixel Pitch |
[Insert pitch, e.g., 2.5mm / 3mm]* |
|
Pixel Count |
[Insert number of LEDs per module]* |
|
Power Consumption |
~0.3W per LED at full white (5V/60mA max) |
|
Operating Temperature |
-20°C to +60°C |
|
Storage Temperature |
-40°C to +85°C |
|
Mounting |
Solder pads / terminal block / optional 3M adhesive backing |
|
Applications |
Pixel screens, LED signs, decorative lighting, gaming rigs, architectural displays |
