The 24V system reduces voltage drop, while 26W/m output delivers strong brightness with stable performance. WS2805 supports dual-signal transmission and breakpoint resume, so one damaged section will not kill the whole run. With CRI ≥90, 180° uniform beam, and a durable 15mm PCB for better heat dissipation, this strip is built for designers, integrators, and DIY makers who want cinema-grade color and reliable digital control in one flexible tape.
🌈 5-in-1 RGBCW Color: Red, Green, Blue, Warm White (2700K) and Cool White (6500K) in one COB chip—vivid fantasy colors plus true tunable white.
✨ Dot-Free COB Light: 840 LEDs/m with COB packaging eliminate visible dots and dark gaps; smooth “light sheet” even at close viewing distance.
🎬 Programmable WS2805 IC: 14 pixels/m support running water, chase, gradient, breathing, and music-sync effects via SPI/addressable controllers.
🛡️ Breakpoint Resume: WS2805 dual-signal design keeps the rest of the strip working if one pixel fails—ideal for commercial and architectural installs.
⚡ 24V Stable & High Density: DC24V lowers current and voltage drop; 26W/m high output with 15mm wide PCB for better heat dissipation and longer life.
Product Specification Sheet — 15mm WS2805 RGBCW Addressable COB LED Strip
|
Category |
Item |
Specification |
|---|---|---|
|
General |
Product Type |
Addressable RGBCW COB LED Strip |
|
LED Technology |
COB (Chip-on-Board), 5-in-1: R+G+B+WW+CW |
|
|
LED Density |
840 LEDs/m |
|
|
Control |
IC Type |
WS2805 (dual-signal, breakpoint resume) |
|
Pixels |
14 ICs / m（14 addressable segments / m） |
|
|
Effect |
Running water, chase, gradient, static, scene mode |
|
|
Electrical |
Input Voltage |
DC 24V |
|
Power |
26W/m（130W / 5m roll） |
|
|
Cutting Unit |
71.42 mm（1 pixel = 60 LEDs） |
|
|
Optical |
White Range |
2700K Warm White + 6500K Cool White |
|
CRI |
Ra ≥ 90（white channels） |
|
|
Beam Angle |
180° |
|
|
Feature |
Dot-free, no hotspot, smooth color mix |
|
|
Physical |
PCB Width |
15 mm |
|
Roll Length |
5 m / roll（custom 10 m / 20 m available） |
|
|
Back Adhesive |
3M VHB tape |
|
|
Environment |
IP Rating |
IP20 default（IP65 / IP67 / IP68 optional） |
|
Working Temp. |
-20℃ ~ +45℃ |
|
|
Lifespan |
35,000–50,000 h |
|
|
Controller |
Compatibility |
WS2805 / SPI addressable controller, WLED, Arduino, DMX512（via decoder）, Tuya / WiFi RGBWW controller |
|
Application |
Cove, cabinet, shelf, TV backlight, bar, stage, architecture, retail display, smart home |
