S20-10-DMX-RGB 1M DMX Pixel Bar for Stage DJ KTV Bar

That’s exactly where the S20-10-DMX-RGB​ comes in: a 1-meter, 24V, full-color RGB, DMX-programmable, waterproof pixel LED bar built for professional entertainment lighting and architectural accent projects alike.

What Is the S20-10-DMX-RGB?

The S20-10-DMX-RGB is a DMX512 pixel linear light​ — basically a rugged, addressable light bar that turns a normal ceiling, truss, wall, or booth edge into a programmable video/strobe/chase element.

• Model:​ S20-10-DMX-RGB

• Length:​ 1000 mm (1 meter)

• Voltage:​ DC 24V

• Color:​ Full-color RGB

• LEDs:​ 60 × SMD5050 RGB LEDs/m

• Pixels:​ 10 individually controllable pixels

• Control:​ DMX512

• Housing:​ Aluminum profile + PC diffuser

• Protection:​ Waterproof (commonly IP65/IP66 class for rain/dust in entertainment fixtures)

• Lifespan:​ Up to 50,000 hours

It’s not just “a colored strip.” Each pixel can be addressed separately, so you can run flowing gradients, running chases, color waves, strobes, builds, fades, and matrix effects​ across dozens of bars.

Why DJs and Venue Owners Love It

1. Real DMX Control, Not Just “Remote + Presets”

Cheap RGB strips blink. DMX pixel bars perform.

With a DMX512 console or software like MADRIX, MadMapper, Resolume, ArKaos, LightKey, or Enttec, you can:

• map each bar as a pixel row

• sync color to BPM

• trigger scenes on cue

• build scrolling text or logos across a wall of bars

• cascade color from stage → truss → back wall → bar counter

That’s why it fits stage shows, DJ booths, nightclubs, KTV rooms, wedding receptions, and immersive brand activations.

2. 10 Pixels per Meter = Clean Motion Effects

Some bars have too few pixels and look “blocky.” Some have too many and overload your DMX universe.

10 pixels per 1M bar​ is a sweet spot:

• smooth enough for gradients

• light enough for long DMX chains

• easy to calculate channels

• great for rhythm-based chases

With 60 SMD5050 LEDs grouped into 10 pixel segments, you get bright output without sacrificing animation quality.

3. 24V = Stable for Long Runs

Unlike 5V pixel tape that drops voltage fast, 24V linear bars​ are much friendlier for:

• truss rigs

• ceiling grids

• facade outlines

• balcony rails

• backbars

• outdoor festival fences

Less voltage drop, less heat, fewer power-injection headaches.

4. Waterproof = Indoor Tonight, Outdoor Tomorrow

IP-rated housing means you can use it in:

• KTV corridors

• club ceilings

• DJ boothes

• beer garden fences

• building outlines

• poolside bars

• outdoor stage wings

Just don’t submerge it. Rain? Dust? Splashes? Fine. Underwater fish tank? No.

Typical Specs at a Glance

Best Ways to Use It

🎧 DJ Booth Edge

Mount bars along the front lip of the booth. Every beat can push a new color toward the crowd.

🍸 Backbar / Shelf Lighting

KTV rooms and lounges look instantly premium when bottles sit in front of animated RGB lines.

🎤 Stage Truss Lines

Hang multiple 1M bars end-to-end for a “pixel video beam” above the performer.

🏙️ Building / Facade Outline

Because it’s 24V and waterproof, it works great for architectural lighting too — not just nightlife.

🎉 Mobile Events

Weddings, brand launches, New Year parties: program a custom color script and let the room “tell a story” over the night.

Installation Tips

1. Use a proper DC24V power supply​ with enough wattage headroom.

2. Use a DMX512 controller / decoder​ — SPI-only controllers won’t give you full DMX addressing.

3. Set DMX start addresses carefully when chaining bars.

4. Prefer milky/opal diffuser​ for soft club glow; clear cover​ for max intensity.

5. For big installs, plan DMX universes:

   • 10-pixel bar = often 30 DMX channels (R/G/B × 10)

   • 512 ÷ 30 ≈ 17 bars per universe (practically fewer if you leave headroom)

6. Use aluminum mounting clips / end caps / threaded rods depending on the fixture version.

Who Should Buy This?

• Club & KTV owners upgrading from static strips

• DJs building a portable pixel rig

• AV/lighting rental companies

• Stage designers and VJs

• Architectural lighting integrators

• Event production agencies

If you want “neon vibe” plus programmable show control, this is the upgrade.

Final Verdict

The S20-10-DMX-RGB 1M 24V waterproof RGB pixel bar​ is one of those products that punches above its price:

✅ True DMX pixel control

✅ Bright SMD5050 RGB output

✅ 24V stability for long runs

✅ Waterproof body for club + outdoor use

✅ 10-pixel density that looks smooth, not messy

✅ Works with MADRIX / MadMapper / Resolume workflows

If your venue still runs “RGB strip + IR remote,” this is your next step into real programmable lighting.

Bottom line:​ Stage looks pro. DJ booth looks alive. KTV looks expensive. Bar looks unforgettable.
